The NPU 10,000 Eco is the largest unit in our range, providing a nominal airflow of 10,000 m³/hr. It is fitted with an advanced EC digital motor which uses less energy without compromising performance, making it more efficient and cheaper to run than previous models. It is typically used in the controlled removal of asbestos-containing materials and is an ideal unit for large scale projects.
Eco features include:
Advanced EC digital motor with soft-start technology which lowers operating costs and improves service life
Excellent power-to-performance efficiency: uses 47% less energy compared to previous models.
SMH 10000 ECO Negative Pressure Unit Features:
Sturdy and robust design, with handles for easier lifting
Polypropylene housing which is easy to clean
Quick and easy pre-filter replacement while in situ
Efficient two-stage air filtration with a pre-filter and a HEPA filter.
Technical Data
Specifications
Case material: Polypropylene Case colour: Grey Weight: 135 kg
Electric
Voltage: 240 V Isolation on/off switch
Airflow & Filters
Nominal airflow: 10,000 m³/hr (5,885 CFM) Noise level (1m, no ducting): 86 dBA Differential pressure gauge: 01250 Pa Prefilter dimensions: 905 x 595 x 97 mm H14 HEPA filter dimensions: 915 x 610 x 292 mm
Dimensions
Case length (A): 1310 mm Case width (B): 800 mm Case height (C): 1169 mm Floor clearance height (D): 113 mm Exhaust outlet diameter (E): 500 mm Exhaust outlet depth (F): 150 mm Cover plate width (G): 800 mm Cover plate height (H): 1106 mm
